Product Overview
Matrix Industrial Traders Belimo-Compatible Electric Rotary Actuators combine robust cast aluminum housing with precision planetary gear trains. Ideal for automating butterfly valves and flanged ball valves across industrial plant piping and district cooling plants, delivering uncompromised torque and long cycle life.
Key Features
- ISO 5211 Standard Flange Mounting: Fits standard F05, F07, F10 valve mounting pads without custom brackets.
- Continuous 3D Optical Position Indicator: Raised dome beacon provides visual valve status from distance and angle.
- Internal Space Heater: Prevents internal condensation in outdoor and high-humidity environments.
- Declutchable Manual Handwheel: Safe, smooth manual positioning without disassembling the motor drive.
- Multi-Voltage Control: Accepts 24V AC/DC, 110V AC, and 230V AC power with modulating 4-20mA / 0-10V control cards.
Technical Specifications
Scroll horizontally to view complete specifications
| Parameter | Standard Specification |
|---|---|
| Output Torque | 50 Nm, 100 Nm, 200 Nm, up to 1000 Nm |
| Operating Angle | 90° ± 5° adjustable |
| Operating Speed | 15 to 30 seconds for 90° travel |
| Enclosure Rating | NEMA 4X / IP66 / IP67 waterproof polyester powder-coated aluminum |
| Motor Duty Cycle | S4 – 70% duty cycle, Class F insulation |
| Limit Switches | 2 x open/close travel switches + 2 x auxiliary dry contact switches |
Applications & Industries
Cooling tower bypass isolation, chiller condenser manifold automation, municipal wastewater aeration lines, chemical distribution, and power station steam condensate loops.
