Product Overview
The Matrix Industrial Traders Industrial Pressure Switch is engineered for critical safety shutdown and pump pressure sequencing. Equipped with micro-adjustment dials and durable phosphor bronze or stainless steel bellows, it provides repeatable switching accuracy across water, air, steam, and refrigeration circuits.
Key Features
- Snap-Action SPDT Microswitch: Delivers instantaneous, bounce-free electrical trip contacts (up to 16A at 250V AC).
- Independent Range & Differential Adjustment: Clear visual scale enables straightforward site calibration.
- High Proof Pressure: Safeguards switch mechanisms against line surges and hydraulic shocks.
- Die-Cast NEMA 4X / IP65 Housing: Weatherproof construction suitable for tough outdoor industrial yards.
Technical Specifications
Scroll horizontally to view complete specifications
| Parameter | Standard Specification |
|---|---|
| Pressure Set Ranges | -0.2 to 8 Bar, 0 to 16 Bar, or 5 to 32 Bar models |
| Switching Contact | 1 x SPDT (Single Pole Double Throw), optional DPDT |
| Electrical Rating | 16A 250V AC / 10A 400V AC |
| Process Connection | G 1/4″ Female or 1/4″ NPT |
| Media Temperature | -20°C to +120°C (Steam up to 180°C with siphon) |
| Enclosure Class | IP65 dust-tight and water-jet protected |
Applications & Industries
Fire pump auto start/stop panels, industrial air compressors, boiler steam pressure limits, chiller low-pressure safety trips, and cooling water circuits.
